Mechanical
Dimensions: 152 x 37 x 31 mm (6 x 1.5 x 1.2")
Weight: 180 g (6.3 oz)
Enclosure Material: US-stabilized plastic
Hardware
Networking Interface: (1) 10/100 BASE-TX (Cat. 5, RJ-45) Ethernet
Power Method: Passive PoE 2-pair (4, 5+; 7, 8 return)
Power Supply: 24V DC, 0.5A gigabit PoE adapter (Not included)
Max. Power Consumption: 7W
Supported Voltage Range: 22–27V DC
RF Connector: Integrated N-type male jack (connects directly to antenna)
Environmental
Ambient Operating Temperature: -40 to 70° C (-40 to 158° F)
Ambient Operating Humidity: 5 to 95% condensing
Shock and Vibration: ETSI300-019-1.4
|
|
|
